TR1-D4 Male End Drain

The Tuf-Tite TR1-D4 is an injection-molded, high-density polyethylene (HDPE) male end drain designed specifically for use with the Tuf-Tite TR1 Trench Drain system. This component snaps directly onto the female end of a trench unit, allowing for efficient horizontal water discharge into standard 4-inch piping systems.

Features:

Snap-On Installation: Engineered to snap easily onto the female end of the TR1 trench drain without complex tools.

Versatile Pipe Compatibility: Accepts 4" SDR35-3034 pipe and 4" 2729 pipe directly; also accepts 4" corrugated pipe when used with an MF-4 pipe connector.

Heavy-Duty Durability: Rated for H-20 wheel loads (235 psi) when installed correctly, making it suitable for high-traffic areas like driveways or loading docks.

Industrial Strength Material: Manufactured from non-corrosive, UV-stabilized HDPE for long-term resistance to environmental wear.

Standardized Dimensions: Measures approximately 2" in length, 5" in width, and 5" in depth.
