NeoFit - Acetal Gray Single Check Valves 8mm (5/16") tube

NeoFit - Acetal Gray Single Check Valves 8mm (5/16") tube

SKU:ACHV88M-G:6PK

Pricing is available for wholesale customers only, please login to see prices.

Interested in becoming a partner?
Click here for more info.

Out of stock

Choose:

The check valve allows fluid to flow one way and prevents reverse flow. Manufactured in acetal copolymer with food grade EPDM O-ring, these fittings are suitable for pure water, potable liquids and other beverage applications.

Features:

  • Allows fluid to flow in one direction
  • Prevents back flow
  • Compact size for use in small spaces
  • Compatible with plastic or copper OD sized tubing
  • Food Quality and suitable for potable liquids and pure water applications
  • Acetal body with food grade EDPM O-Ring
  • Made with Lead Free materials


Fittings Comparison:
Size NEO: Working PSI @ Temp JG: Working PSI @ Temp JG: Working PSI @ Temp
1/4" 290psi @ 68F/ 232psi @ 150F 230psi @ 68F/ 150 psi at 150F 230psi @ 68F/ 100 psi at 150F
3/8" 232psi @ 68F/ 203psi @ 150F 150psi @ 68F/ 100 psi at 150F 170psi @ 68F/ 100 psi at 150F
1/2" 203psi @ 68F/ 116psi @ 150F 150psi @ 68F/ 100 psi at 150F 170psi @ 68F/ 100 psi at 150F
Certifications NEO: NSF 51 & 61 Certified JG: NSF 51 & JG: NSF 51 & 61 Certified DM Fit: NSF 51 & 61 Certified
Size NEO: Max Torque JG: Max Torque DM Fit: Max Torque
1/4" 1ft/lb (1.5nm) 1ft/lb (1.5nm) 1ft/lb (1.5nm)
3/8" 2ft/lb (3 nm) 2ft/lb (3 nm) 2ft/lb (3 nm)
1/2" 2ft/lb (3 nm) 2ft/lb (3 nm) 2ft/lb (3 nm)

Documents

NeoFit - Acetal Gray Single Check Valves 8mm (5/16
